UAV Multirotor RC Car Lipo battery pack 3S 11.1v 70C 2200mah 803496

UAV Multirotor RC Car Lipo battery pack 3S 11.1v 70C 2200mah 803496

    • UAV Multirotor RC Car Lipo battery pack 3S  11.1v  70C 2200mah 803496
    • UAV Multirotor RC Car Lipo battery pack 3S  11.1v  70C 2200mah 803496
  • UAV Multirotor RC Car Lipo battery pack 3S  11.1v  70C 2200mah 803496

    Product Details:

    Place of Origin: GUANGZHOU
    Brand Name: TAC
    Certification: ROHS
    Model Number: 11.1v 2200mah

    Payment & Shipping Terms:

    Minimum Order Quantity: 500set
    Price: by quantity
    Packaging Details: 2 set/ inner box 5box / carton
    Delivery Time: 25-28days
    Supply Ability: 10000 set/ month
    Detailed Product Description
    Material: Polymer Lithium Ion Voltage: 11.1
    Capacity: 2200mah Discharge Rate: 70C
    Size: 08*34*96mm Cut Off Voltage: 9V
    PCB: With Pcb Pvc Color: Blue

    UAV Multirotor RC Car Lipo battery pack 3S 11.1v 70C 2200mah Size 803496





    Specification



    No. Items Specifications



    1

    Nominal Capacity

    1200mAh

    1.0C Standard discharge



    2

    Minimum Capacity

    1200mAh
    3

    Nominal Voltage

    3.7V

    Operation Voltage



    4

    Delivery voltage



    3.80~3.95V

    Within 10 days from Factory



    5

    Charge Voltage



    4.2V±0.03V

    By standard charge method



    6

    Standard charging method



    0.5C constant current,4.2V constant voltage charge to 4.2V,continue charging till current deline to ≤0.01C



    7

    Charge current



    0.5C 600mA

    Standard charge, charge time:2.5h(Ref)



    1.0C 1200mA

    Rapid Charge, charge time:1.5h(Ref)



    8

    Standard discharging method



    1.0C constant current discharge to 3.0V,
    9

    Cell Internal Impedance



    ≤20mΩ

    Internal resistance measured at AC 1KHZ after 50%



    Safety test method



    1 Free fall test

    The battery to be fully charged in accordance with stnadard charge condition, then drop the battery three times from a height of 1,0 m onto a concrete floor. The batteries are dropped so as to obtain impacts in random orientations.

    No explosion,No leakage,No fire



    2 Vibration test

    After standard charging, fixed the cell to vibration table and subjected to vibration cycling that the frequency is to be varied at the rate of 1Hz per minute between 10Hz and 55Hz, the excursion of the vibration is 1.6mm. The cell shall be vibrated for 30 minutes per axis of XYZ axes.

    No explosion,No leakage,No fire



    3 Crush test

    Fully charged the battery in accordance with standard charge condition, the battery is to be crushed between two flat plates. Continuous to applied force on battery of 13kN(17.2Mpa),stopped until a pressure reading of 17.2Mpa is reached on the hydraulic ram

    No explosion, No fire



    4 Shock test

    The fully charged battery is secured to the testing machine by means of a rigidmount which will support all mounting surfaces of the cell or battery. The battery is subjected to a total of three shocks of equal magnitude. The shocks are applied in each of three mutually perpendicular directions. At least one of them shall be perpendicular to a flat face.For each shock the cell or battery is accelerated in such a manner that during the initial 3 milliseconds the minimum average acceleration is 75 gn. The peak acceleration shall be between 125 gn and 175 gn. Cells or batteries are tested in an ambient temperature of 20~25℃

    No explosion,No leakage,No fire



    AND MORE FOLLOW THE UN38.3 STANDARD



    Warranty:



    for 1years from the date of shipping. Any other problem caused by malfunction of the equipment or mix-use of the cell is not under this warranty.

    Tac battery will be responsible for replacing the cell against defects or poor workmanship





    Other Single battery model



    9590190MP-16000 16000 3.7
    7270170MP-10000 10000 3.7 30 7.2 2.2 6.88 69.98 169.87 1.7 182.49 5C
    9759156MP-10000 10000 3.7 29.5 9.7 2.2 9.37 58.85 155.77 1.9 188.12 5C
    7270170MP-10000 10000 3.7 30 7.2 2.1 6.88 69.98 169.87 1.7 182.49 5C
    9559156MP-11000 11000 3.7 28 9.5 2.2 9.47 58.83 157.5 1.6 196.55 5C
    7870170HP-12000 12000 3.7 37 8.0 2 8.05 70.09 170.93 1.5 218.01 20C
    9470170MP-13000 13000 3.7 28 9.4 2.0 9.27 69.89 169.85 1.6 239.6 5C
    9070220HP-14000 14000 3.7 36 9.0 2.0 8.4 70.8 213 1.6 286.39 20C
    1170170MP-15000 15000 3.7 30 11 2.1 10.47 68.86 169.96 1.7 266.65 5C
    1184165HP-16000 16000 3.7 40 11 1.7 10.8 83.88 165.24 1.4 324.14 20C
    9884165MP-16000 16000 3.7 40 9.8 1.9 9.37 83.42 164.49 1.5 293.92 5C
    1170170HP-16000 16000 3.7 30 11 2.0 10.96 69.94 169.99 1.6 297.62 20C
    1190190HP-21000 21000 3.7 47 11 1.7 10.78 88.98 189.95 1.4 421.36 20C
    1190190MP-22000 22000 3.7 46 11 2.0 10.85 89.96 189.99 1.5 400.75 5C
    1290190P-22000 22000 3.7 47 12 2.0 11.93 89.98 189.98 1.5 436.74 15C





    Photos



    UAV Multirotor RC Car Lipo battery pack 3S  11.1v  70C 2200mah 803496
