Home ProductsLithium Ion Cylindrical Battery

ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH

ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH

    • ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH
    • ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH
    • ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH
  • ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH

    Product Details:

    Place of Origin: guangzhou
    Brand Name: TAC
    Certification: CE\UN38.3\ROHS
    Model Number: 21700

    Payment & Shipping Terms:

    Minimum Order Quantity: 5000pcs
    Price: USD 2.5 each pcs
    Packaging Details: 20pcs/ inner box , 5 box/ carton
    Delivery Time: 10 work days
    Supply Ability: 300000pcs /month
    Contact Now
    Detailed Product Description
    Material: Lithium Ion Battery Voltage: 3.7v
    Capacity: 4000mah Discharge Rate: 0.2C
    Size: D; 21mm H:70mm PVC Color: Blue
    Circle Life: 500 Times Current: Max Discharge Current 0.2C
    Warranty: 12 Months Accemble: Acceptable

    21700 Lithium Battery For Electrical Vehicle 3.7V 4000MAH



    Specification for 21700 Lithium Battery For Electrical Vehicle 3.7V 4000MAH


    No. Items Specifications

    Remark

    1

    Nominal Capacity

    4000mAh

    0.5C Standard discharge



    2

    Minimum Capacity

    3800mAh
    3

    Nominal Voltage

    3.7V

    Mean Operation Voltage



    4

    Delivery voltage

    3.70~3.9V

    Within 10 days from Factory



    5

    Charge Voltage



    4.2V±0.03V

    By standard charge method



    6

    Standard charging method



    0.5C constant current,4.2V constant voltage charge to 4.2V,continue charging till current decline to ≤0.01C



    7

    Charge current

    0.2C 400mA

    Standard charge, charge time about 7h(Ref)



    0.5C 2000mA

    Rapid Charge, charge time about: 3.5h(Ref)



    8

    Standard discharging method



    0.5C constant current discharge to3.0V,
    9

    Cell Internal Impedance



    ≤50mΩ

    Internal resistance measured at AC 1KHZ after 50% charge





    Cell Electrical Performance



    No Items Test Method and Condition/

    Criteria
    1

    Rated Capacity at 0.2C(Min.)



    After standard charge, the capacity shall be measured on 0.2C discharge till the voltage discharge to3.0V,



    ≥3800mAh ≥100%

    Rated Capacity at 0.5C(Min.)



    After standard charge, the capacity shall be measured on 0.5C discharge till the voltage discharge to 3.0V,



    ≥3686mAh ≥98%

    Rated Capacity at 1C(Min.)



    After standard charge, the capacity shall be measured on 1C discharge till the voltage discharge to 3.0V,



    ≥3534mAh ≥96%
    2

    Cycle Life



    Charging and discharging battery as blew conditions

    0.2C standard charge to 4.2V end-off

    0.2C standard discharge to 3.0V cut-off

    Continuous charge and discharge for 300 cycles ,the capacity will be measure after the200th cycle



    ≥80% of initial capacity
    3

    Capacity retention



    The battery to be charge in accordance with standard charge condition at 20~25℃,then storage the battery at an ambient temperature 20~25℃ for 28 days.

    Measure the capacity after 30 days with 0.2C at 20~25℃ as retention capacity



    Retention capacity



    ≥85%



    Application for 21700 Lithium Battery For Electrical Vehicle 3.7V 3000MAH 30C

    1. EV / E-CAR /  E-SCOOTER /E-Bike
    2. Energy storage system// Portable ESS
    3. power tool /
    4. Solar production

    Package For Bulk

      20-50 pcs each box and 4 box pcs in one standard export carton

      Tac Also support display box and specially color carton for OEM ODM order



      ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH



    ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH



    Delivery Time Information

    7-10 days for bulk cell base on industry pack , this is normal model , we prepare the stock continue

    25-30 days for battery pack after the customer confirm the detail accessories for examples PCB Connector etc.



    Period of Warranty



    The period of warranty is one year from the date of shipment. We guarantees to give a ccin case of cells with defects proven due to manufacturing process instead of the customer abuse and misuse.



    The suggestion for Storage of the Lithium-ion Batteries

    The batteries should be stored at room temperature, charged to about 30% to 50% of capacity.
    We recommend that batteries be charged about once per half a year to prevent over discharge.



    Similar Model for Lithium ion cylindrical Battery

    MODEL CAPACITY VOLATGE
    ICR10440 250-400MAH 3.7V
    ICR14500 450-600MAH 3.7V
    ICR17335 750-900MAH 3.7V
    ICR18490 1100-1500MAH 3.7V
    ICR18500 1500-1800MAH 3.7V
    ICR18650 2000-2800MAH 3.7V
    ICR26650 3000-3300MAH 3.7V
    ICR20700 3500MAH 3.7V
    ICR21700 4000MAH

    3.7V





    Battery Photo for Similar Model ( Bulk Pakage)

    ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH



    ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH





    Lithium-ion battery pack made by ICR21700 4000MAH 3.7V



    ROHS 21700 Lithium Ion Cylindrical Battery For Electrical Vehicle 3.7V 4000MAH
