OEM Polymer Lithium Ion Batteries 2500mAh 3.7V For Small Medical Device

    • OEM Polymer Lithium Ion Batteries 2500mAh  3.7V For Small Medical Device
    • OEM Polymer Lithium Ion Batteries 2500mAh  3.7V For Small Medical Device
  • OEM Polymer Lithium Ion Batteries 2500mAh  3.7V For Small Medical Device

    Product Details:

    Place of Origin: guangzhou
    Brand Name: Tac or OEM \ODM
    Certification: UL, Rohs
    Model Number: 084068 3.7v 2500mah

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 PCS
    Price: usd2.2
    Packaging Details: 20 pcs in one pallet, 10 pallet in one carton
    Delivery Time: 14-25 days
    Payment Terms: T/T, LC,Paypal etc.
    Supply Ability: 30K/Day
    Contact Now
    Detailed Product Description
    Material: Polymer Lithium Voltage: 3.7-4.2v
    Capacity: 2500mah Circle Life: 500 Times DOD 100%
    Warranty: 12 Months Pack: Workable
    PCB: With PCB OEM \ODM: Yes
    Certification: UL UN38.3 Accemble: PCB Wire And Connector

    Lion Polymer Battery 2500mAh 3.7V Cells For Small Medical Device

    Specification



    Item

    Rated Performance

    Remark

    Rated Capacity

    Typtical

    8000mAh

    Standard discharge(0.2C
    C5A) after Standard charge

    Nominal Voltage

    3.7V-4.2V

    Mean Operation Voltage
    During Standard Discharge
    After  Standard  Charge

    Voltage at end of
    Discharge

    3.0V

    Discharge Cut-off Voltage

    Charging Voltage

    4.2±0.03V



    AC  (1KHz) Impedance
    New Cell Max.(mW)

    ≤40mΩ



    Standard charge

    Constant Current 0.5C5A
    Constant Voltage 4.2V
    0.01 C5A cut-off

    Charge time : Approx 4.0h

    Standard discharge

    Constant current 0.2 C5A
    end voltage 3.0 V



    Fast charge

    Constant Current 1C5A
    Constant Voltage 4.2V
    0.01 C5A cut-off

    Charge time : Approx 2.5h

    Fast discharge

    Constant current 1 C5A
    end voltage 3.0 V



    Maximum Continuous
    Charge Current

    1 C5A



    Maximum Continuous
     Discharge Current

    1.5 C5A



    Operation Temperature

    Charge: 0~45℃

    60±25%R.H.
    Be Cell

    Discharge: -20~60℃

    Storage Temperature


    Less than 1 year: -20~25℃

    60±25%R.H.
    at the shipment state

    less than 3 months: -20~40℃

    Weight for cell

    Approx :25g

    single Cell

    Cell  Dimension

    Length: Max.40.5mm

      Dimension without pcb

    Width: Max.68.5mm

    Thickness: Max. 8.2mm




    Similar Model for lipo battery

    SIZE:
    288097

    CAPACITY:
    2250

    3069982100
    442944600
    09102165NM5510000
    0530100850
    85200235F(HS)22000
    251011565000
    251011565000
    442543400
    6337672000
    29631463300
    2669922100
    2669922100
    85200235F(HS)22000
    85200235F(HS)22000
    85200235F(HS)22000
    0530100850
    2669922100
    85200235F(HS)22000


    And More with your require


    Application for Lion Polymer Battery 2500mAh 3.7V Cells For Small Medical Device

    1. Various street Lights, model aircraft, miner's lamp, safety helmets, safety headlights;
    2. Wireless meter reading, wireless ordering, wireless data transmitter.
    3. E-books, mobile DVD, mobile TV, mobile scales, handheld computer,
    4. positioning devices
    5. GPS for the car
    6. car starter
    7. Portable VTR/TV, tape recorders, radios, etc.
    8. ​Power tools, lawn mowers and vacuum cleaners
    9. ​Cameras and photographic equipment
    10. ​Computers etc.
    11. ​Portable measuring equipment
    12. ​Various power toys and recreational equipment
    13. ​Uninterruptible Power Supply
    14. ​Communications and electric equipment


    Packing and delivery
    the battery packed by plastic pallet
    20 pcs in one pallet and 10 pallets in one export carton
    normally 15 days for cell and 25-30 days for pack after the order confirm
    OEM Polymer Lithium Ion Batteries 2500mAh  3.7V For Small Medical Device


    Product photos

    OEM Polymer Lithium Ion Batteries 2500mAh  3.7V For Small Medical Device
