CR2025 3.0V 160mA Primary Lithium Coin Cell Battery for LED Light

CR2025 3.0V 160mA Primary Lithium Coin Cell Battery for LED Light

Product Details:

Place of Origin: GUANGZHOU
Brand Name: TAC
Certification: UL,ROHS
Model Number: CR2025

Payment & Shipping Terms:

Minimum Order Quantity: 1000PCS
Price: usd 0.05-0.1
Packaging Details: 200PCS/box, 5600Pcs/Carton, Weigt:9.9KG Size:34*28*30cm
Delivery Time: 14days after order
Payment Terms: T/T, LC, Paypal etc.
Supply Ability: 100,000PCS/Day
Get Best Price Contact Now

Detail Information

Material: Primary Lithium Coin Cell Voltage: 3.0V
Capacity: 160mah Size: 20*25mm
Rechargeable: NO Life: 5 Years
Storage Temperature: -10~50℃ Off-load Voltage: ≥3.25
Highlight:

lithium cell battery

,

cr2016 batteries

Product Description

CR2025 3.0V 160mA Primary Lithium Coin Cell Battery for LED Light



Battery Type button coin cell 3v lithium battery CR2025
Brand Name TAC or OEM
Model CR2025 CR2016 CR2032 CR2450 CR1620 CR1616
Voltage 3.0V
Material Lithium Manganese Battery
Capacity 75mAh- 600mAh
Certifications CE ROHS SGS MSDS
Size 20.0mm*15mm
Jacket Bare or Yellow Pvc
Samples Service Free samples available
If Rechargeable No
Storage life 1year
Package Blister card pack,bulk tray pack or your customized package
Shipping 2-3 working days for samples; 15-20 days for batch goods.
Payment Term T/T,  L/C, Paypal, etc







Similar products:



MODEL

NOMINALVOLTAGE

NAMENAL

CAPACITY

STANDARD

DISCHARGE

CURRENT

MAX

DISCHARGE

CURRENT

PULSE

DISCHARGE

NAMINAL

WEIGHT

CR1025

3.0V

30mAh

0.1mA

0.2mA

5mA

0.9g

CR1216

3.0V

25mAh

0.1mA

0.2mA

5mA

0.7g

CR1220

3.0V

38mAh

0.1mA

0.2mA

5mA

0.9g

CR1616

3.0V

45mAh

0.1mA

0.2mA

5mA

1.2g

CR1632

3.0V

120mAh

0.1mA

0.3mA

5mA

2.3g

CR2016

3.0V

75mAh

0.1mA

0.3mA

10mA

1.8g

CR2025

3.0V

150mAh

0.1mA

0.3mA

10mA

2.5g

CR2032

3.0V

220mAh

0.2mA

0.4mA

12mA

3.1g

CR2330

3.0V

260mAh

0.2mA

0.5mA

12mA

4.0g

CR2430

3.0V

270mAh

0.2mA

1.0mA

15mA

4.2g

CR2450

3.0V

600mAh

0.5mA

1.5mA

20mA

6.7g





Battery Picture

CR2025 3.0V 160mA Primary Lithium Coin Cell Battery for LED Light 0

OBA check below item list after we shipping out



No ITEM TEST METHODS STANDARED
1 Dimensions Using vernier caliper (accuracy≥0.02) while avoiding short-circuit Diameter 20.0 (-0.2) mm
Height 2.5 (-0.2) mm
2 Off-load voltage Using multimeter (accuracy≥0.25%) internal resistance≥1MΩ ≥3.25 v
3 Instantaneous short-circuit current Time of short-circuit should be less than 0.5 second and avoid repeated test within half an hour ≥160 mA
4 Appearance Eyeballing Bright, clean, no rust, no leakage, And no flaw
5 Capacity Continuously discharge for 8 hours with load 15k, temperature at 20~25℃, humidity at 65±20% till 2.0v end-voltage (for fresh battery only: within 3 months ) ≥1000 h
6 Vibration test Put battery on the platform of the vibrations machine, start the machine and adjust the frequency form 10 times per minute to 15 times per minute. keep it running for an hour Characteristics keep stability
7 Leakage at high temperature Stored under temperature (45℃) for 30 days Leakage rate≤1%
8

Over discharge

Test

After 2.0v end-voltage, continuously discharged for 5 hours No leakage allowed
