Dark Grey 1000W Portable Energy Storage System Power Station With AC Output
Product Details:
| Place of Origin: | GUANGZHOU |
| Brand Name: | ODM OR OEM |
| Certification: | MSDS REACH ROHS UN38.3 |
| Model Number: | QE02A 1000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50PCS |
|---|---|
| Price: | USD400 |
| Packaging Details: | 1pcs per carton |
| Delivery Time: | 25 days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 10000PCS per month |
|
Detail Information |
|||
| Material: | Li-NiCoMn | Power: | 1065Wh |
|---|---|---|---|
| Capacity: | 288000mAh | Size: | 413mm×203mm×232mm |
| Weight: | 12.5KG | Cycle Life: | 1000 Times |
| High Light: | 1000W Portable Energy Storage System,Dark Grey Portable Energy Storage System |
||
Product Description
Dark Grey 1000W Power Station Portable Energy Storage System With AC Output European Standard
Feature:
1. Plastic case
2. Color Optional
3. LCD Power Display/Discharging time/Error Warning/AC DC USB Status
4. Li-NiCoMn
5. 1000 Cycles
| Battery | Cell type | Li-NiCoMn |
| Cell model | 21700 | |
| Capacity/mAh | 4000 | |
| Quantity/pcs | 72 | |
| Single cell voltage/V |  3.7 |
|
| Cell life | 1000 Cycles(≥80 ) | |
| Grouping type | 6S12P | |
| Capacity and Energy |
Energy/Wh | 1065Wh |
| Capacity/mAh | 288000mAh | |
| AC Interface | AC Quantity | 2CN/2JP/2US 1EU/1UK |
| Interface standard shape | ||
| Output Waveform Type | Pure Sine Wave | |
| Inverter Type | Unidirectional Inverter | |
| Rated Output Voltage | US/JP: 100V-120V CN/EU/AU/UK: 220V-240V |
|
| Power Rating/W | 1200W | |
| Peak Power/W | 2400W | |
| Overload Protection | Protection Method: 2400W/1S | |
| Short Circuit Protection | √ | |
| Default Frequency | US/JP: 60Hz CN/EU/AU/UK: 50Hz |
|
| Frequency Switch | √ | |
| Sleep Mode | √ |
|
Conversion Efficiency |
≥90 | |
| Cigarette Lighter Interface |
Quantity | 1 |
| Model/Specification | 12V/10A | |
| USB Interface | Quantity | USB-A1*2: 5V/2.4A USB-A2(QC3.0):5V/3A, 9V2A, 12V1.5A Type-C(PD3.0): 5V/9V/12V/15V/20V3A 65W(Max) |
| USB-C USB-C interface |
PD Interface Bi-directional Charging and Discharging | √ |
| DC interface | Quantity | 2 |
| DC Interface Type | 5525 | |
LED Light |
Avaliable | √ |
| Power | 2W | |
| Modes | 1, Always On 2, Medium Brightness; 3, Blink Mode 4, SOS Mode |
|
Solar Input Interface |
Type | 7909 |
| Charging Voltage Range | 12V~30V | |
| Power | 200W | |
| MPPT | √ | |
| Parallel Port | × | |
| Full Charge | 7~8h | |
| Adapter Charging | Adapter Specifications |
120W/180W(Optional) |
Adapter Full Charge Time |
≈9h/ 6h(Optional) | |
| AC Charging (Wall Charger) |
Charging Power | 120W/180W(Optional) |
| Full Charge Time | ≈9h/ 6h(Optional) | |
| PDPD Charging | PD Charging Power | 65W |
| PD Full Charge Time | ≈16h | |
| Anderson Charging | Charging Power | × |
| Full Charge Time | × | |
| Combination Charging | Avaliable | √ |
| Combination Charging Type |
DC180W+PD65W | |
| Full Charge Time | ≈4.5h | |
| Simultaneous Charge-and-Discharge Function |
√ | |
| Noise Level | No Load Noise | ≤45dB |
| Full Load Noise | ≤50dB | |
| UPS Function | Avaliable | × |
| Switching Time (Battery-powered to Mains-Powered) |
× | |
| Operating Temperature | -15～40℃ | |
| Storage Temperature | -20～+60℃ | |
| Storage Method | Charge the product regularly to keep the power above 60 |
|
| Dimension (L*W*H) |
Product | 41.3×20.3×23.2 CM |
| Package | 47×26×34.5 CM | |
| Packaging | Inner Packaging | Color Box |
| External | √ | |
| Product Weight |
Net Weight/KG | ≈ 10 KG |
| Gross Weight/KG | ≈ 12.5 KG | |
| Global Certification | CE/RoHS/FCC/PSE/KC UL2743 |
|
| Product Liability Insurance | Global Insurance | |
| Technical Points | 1, PD Interface Bi-directional Charging and Discharging 2,Accurate power control 3, Low failure rate and stable quality 4, Easy maintenance |
|
| Selling Point | Accurate power control/Cost effective |
|
| Future Upgrade | Series Products/Bi-directional fast charging (bi-directional inverter) | |
