LiFePO4 51.2V 100Ah 5kWh Deep Cycle Battery Pack Built - In Smart BMS Backup
Product Details:
Place of Origin: | GUANGZHOU & SHENZHEN |
Brand Name: | TAC |
Certification: | IEC62619/CE/UN3.83/MSDS/ ROHS |
Model Number: | SF16S1001V0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 50 pcs |
---|---|
Price: | usd 1 |
Delivery Time: | 7-25 days after order confirm |
Payment Terms: | L/C, T/T |
Supply Ability: | 50000 per week |
Detail Information |
|||
Combination: | Combination 16S1P | Capacity: | 100Ah |
---|---|---|---|
Nominal Voltage: | 51.2V | Internal Impedance: | ≤50mΩ |
Battery Dimensions: | 459.3*440*133.5mm | Wight Of Battery: | 45 KG |
Cycle Life: | 4000 @ 25℃ 90% DOD | Relative Humidity: | 5% To 95% Relative Humidity |
Dormant Power Consumption: | ≦100uA | Standard Charging Current: | 33A |
High Light: | 5kWh Deep Cycle Battery Pack,LiFePO4 Deep Cycle Battery Pack |
Product Description
NO |
Project |
Qualification |
Remarks |
2.1 Technical requirements for battery module | |||
2.1.1 |
Minimum capacity |
Rated capacity*97% |
0.5C/25℃ |
2.1.2 |
Rated capacity |
100Ah | |
2.1.3 |
Nominal voltage |
51.2V |
16 Series |
2.1.4 |
Chassis dimensions |
||
2.1.5 |
Chassis material |
Q235 | |
2.1.6 |
Waterproof grade |
IP30 | |
2.1.7 |
Charging maximum voltage |
58.4V | 3.65V/pcs |
2.1.8 |
Discharge minimum voltage |
40V | 2.5V/pcs |
2.1.9 |
Standard charging current |
0.33C | |
2.110 |
Max continuous charging current |
1C |
|
2.1.11 |
Standard discharge current |
0.33C | |
2.1.12 |
Max continuous discharge current |
1C | |
2.1.13 |
Cycle life |
≥3000 cycles |
0.2C charging, discharge/25℃/ 80%DOD |
2.1.14 |
Weight |
45.0KG |
(based on the actual weight of the product) |
2.1.15 |
Discharge operating temperature range |
-20~+65℃ | Try to avoid the battery being exposed to high temperature (≥35℃) for a long time. High temperature and low power will easily lead to accelerated degradation of battery performance. |
2.1.16 |
Storage temperature |
-20~+50℃ | SOC40~60% |
2.1.17 |
Relative humidity |
5~95% |
No condensation, battery system working properly |
2.1.18 |
Height |
<3600m | |
2.1.19 |
Quality guarantee period |
3 years |
3-year free warranty maintenance |
2.1.20 |
Shipment with electricity |
SOC:20%-60%: | 51V-52.8V |
2.1.21 |
communication port. |
RS 232*1+CAN*2 | |
2.1.22 | Run, alarm LED light display |
LED light (green,red) |
|
2.1.23 |
Anti-theft function |
Not |
|
2.1.24 |
Communicating protocol |
CAN protocol | |
2.1.25 |
Charging limit current |
20A | |
2.1.26 |
Reverse protection |
Not |
|
2.1.27 |
Dial switch |
6 bit binary |
|
2.1.29 |
Display screen |
Yes |
|
2.1.29 |
Dry connect |
Not |
|
2.1.30 |
Capacitive load |
30000uF(Max) |
|
2.1.31 |
Heating film |
200W |
6.Cautions
