Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh

Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh

    • Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh
    • Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh
  • Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh

    Product Details:

    Place of Origin: guangzhou
    Brand Name: Tac
    Certification: UL, Rohs
    Model Number: 3.7V 2300mAh

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000Blister
    Price: usd 3.0
    Packaging Details: 5 pcs sample 3days after order Mass order with stock 15days after T/T Without stock 45days
    Delivery Time: 14days after order
    Payment Terms: T/T, LC,Paypal etc.
    Supply Ability: 30K/Day
    Contact Now
    Detailed Product Description
    Material: Polymer Lithium Ion Batteries Capacity: 580mah
    Voltage: 3.7-4.2v Circle Life: 500 Times
    Warranty: 1 Year Size: 05*30*40mm
    Type: Soft Pack Square Assemble: Workable

    GSP053040 3.7V 580mAh Polymer Lithium Ion Battery With PCB



    Feature :



    1.High energy density lithium polymer battery than normal lithium cylindrical cell

    2.Deep Circle and Long life  more than 500 times

    3.The battery pack with protect board in overcharged discharged and short circle performance

    4.Flexible size Thinner design & lighter weight with aluminum-plastic composite

    5.OEM & ODM services for special size of lithium polymer cell and pack

    6.Easy to assemble with mounted connectors (Molex, tag and terminal);

    7.Rigorous testing to ensure the quality of all lithium polymer batteries;



    Specification for GSP053040 3.7V 580mAh Polymer Lithium Ion Battery With PCB



    No.

    Item

    Rated Performance

    Remark

    1

    Rated Capacity

    Minimum

    580mAh

    Standard discharge(0.2C

    C5A) after Standard charge

    2

    Nominal Voltage

    3.7V

    Mean Operation Voltage

    During Standard Discharge

    After  Standard  Charge

    3

    Voltage at end of

    Discharge

    3.0V

    Discharge Cut-off Voltage

    4

    Charging Voltage

    4.2±0.03V



    5

    AC  (1KHz) Impedance

    New Cell Max.(mW)

    ≤60mΩ



    6

    Standard charge

    Constant Current 0.5C5A

    Constant Voltage 4.2V

    0.01 C5A cut-off

    Charge time : Approx 4.0h

    7

    Standard discharge

    Constant current 0.2 C5A

    end voltage 3.0 V



    8

    Fast charge

    Constant Current 1C5A

    Constant Voltage 4.2V

    0.01 C5A cut-off

    Charge time : Approx 2.5h

    9

    Fast discharge

    Constant current 1 C5A

    end voltage 3.0 V



    10

    Maximum Continuous

    Charge Current

    1 C5A



    11

    Maximum Continuous

     Discharge Current

    1.5 C5A



    12

    Operation Temperature Range

    Charge: 0~45℃

    60±25%R.H.

    Be Cell

    Discharge: -20~60℃

    13

    Storage Temperature

    Range

    Less than 1 year: -20~25℃

    60±25%R.H.

    at the shipment state

    less than 3 months: -20~40℃

    14

    Weight

    Approx :43g

    Bare Cell

    15

    Cell  Dimension

    Length: Max.40.5mm

    Initial  Dimension

    Width: Max.30.5mm

    Thickness: Max. 5.2mm



    Application for GSP053040 3.7V 580mAh Polymer Lithium Ion Batteries With PCB

    Auto Jump starter

    UAV

    motorcycle starting battery

    power bank

    portage back up

    energy storage system

    RC model

    blue tooth

    Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh

    Packing Manners



    the cell put into specially tray, normally 20 pcs for each tray

    and 10 tray for one standard export carton

    Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh

    Sample  Policy

    Support OEM and ODM Let  us know your detail requirements of the your project. We can design various battery samples as customer's requirement.

    we can issue free samples less than 5 cell  if the buyer would like to charge for the shipping fee

    Guarantees

    Normally one year warranty, if have any question about our products, you can call us, or tell us by e-mail, we will give you response within 24 hours in working days. we will issue the 8d report and replace the good productions as soon as possible

    Export/Import Processing Support

    We have professional forward team , and our products conform to requirements of export certificates and package. we have the ability to transport DG goods by sea, air, and the third-party logistics. we can make certificates upon client's demands.

    After Sales Service

    24 hours after sales service could be reached,all our product have one year warranty, if have any question about our products, you can call us, or tell us by e-mail.



    Similar Battery Picture

    Polymer Lithium Ion Batteries for Vidicon Camera GSP053040 3.7V 580mAh



    Part model list for Lithium polymer battery cell



      Model                               capacity

    CF903040J03 1000mAh
    CF903048J03 820mAH
    CF903048J15 1000mAh
    CF903052J25 1200mAh
    CF903475J20 2000mAh
    CF923048J15 1100mAh
    CF982070J25 1500mAh
    CF982075J15 1500mAh
    CF982540J20 900mAh
    CF982870J25 1500mAh
    LC0362248RH03 80mAh
    LCO053527RH03 12mAh
    LCO1002428RH05 650mAh
    LCO1004045RH10 1780mAh
    LCO1103048RH01 1800mAh
    LCO1103450RH03 2000mAh
    LCO1202222RH20 280mAh
    LCO202051RH03 120mAh
    LCO283050RH05 360MAH
    LCO2866103RH01 2500mAH
    LCO300923RH20 25mAh
    LCO302025RH10 100mAh
    LCO303046RH03 12mAh
    LCO304860RH01 900mAh
    LCO3060134RH03 3625mAH
    LCO307095RH01 2500mAH
    LCO345054RH03 900mAh
    LCO352042RH03 220mAh
    LCO352044RH10 270mAh
