• Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge
  • Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge
  • Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge
  • Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge
Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge

Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge

Product Details:

Place of Origin: SHENZHEN
Brand Name: TAC OEM ODM
Certification: MSDS REACH ROHS
Model Number: IFM2650-24V -30AH E2

Payment & Shipping Terms:

Minimum Order Quantity: 50 PCS
Price: USD 500
Packaging Details: 1pcs for one bag with UN38.3
Delivery Time: 7-25 days after order confirm
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 units/month
Get Best Price Contact Now

Detail Information

Material: LiFePO4 26650 24V 30Ah Circle Life: 2000 Times
Capacity: 30ah Voltage: 24v
Warranty: 12months Housing: Abs +pc
Bms: Including Of Cell: IFR26650 3.2V 3300MAH
Size: 69*147*540mm Discharge Current: 7A
High Light:

lifepo4 battery pack

,

lithium iron phosphate battery pack

Product Description

Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge

Solar Street Light 12V  24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge





Specification For Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge





No.

Item

General Parameter

Remark

1

Rated Capacity

33Ah

Standard discharge(0.2 C5)after standard charge(0.2 C5)

2

Minimal Rated

Capacity

30Ah

3

Nominal Voltage

25.6V



4

Cycle Life

Higher than 60% of the Initial Capacity of the Cells

◆Charge: CC@0.2C to 14.6V, then CV till current to 0.05C

◆Rest: 30min.

◆Discharge: 0.2C to 10.0V

◆Temperature:20±5℃

◆Carry out 2000cycles

5

Discharge cut-off voltage

16 V

10.0V( recommended)

6

Charging cut-off voltage

29.2V

14.6V (recommended)

7

Cell and assembly method

IFR26650EC-3.3AH

4S1P

8

Housing material

PVC





Charge and Discharge Performance





9

Standard charge

0.2C constant current(CC) charge to 14.6V,then constant voltage (CC)14.6V charge till charge current decline to ≤0.05C

Charge time : Approx 7h

10

Standard discharge

Constant current 0.2C

Cut-off voltage 10.0V



11

Maximum Charge Current

4.5A



12

Continuous Discharge Current

7A



13

Operation Temperature Range

Charge: 0~45℃

60±25%R.H.



Discharge: -10~60℃

14

Storage Temperature Range

Less than 1 year : 0~25℃

60±25%R.H.

at the shipment state

Less than 3 months:-5~35℃

15

Weight

Approx: 7.5Kg



16

Max.Dimension

High:69mm



For battery pack

Width: 147mm

Length: 540mm



Application

Solar Street Light 12V 24V Solar Battery LiFePO4 30Ah Waterproof Standard Discharge 0
