26650 12V LiFePO4 Battery Pack High Power  High Rate For Power Tool

26650 12V LiFePO4 Battery Pack High Power High Rate For Power Tool

Product Details:

Place of Origin: SHENZHEN
Brand Name: TAC OEM ODM
Certification: MSDS REACH ROHS
Model Number: IFR 26650 2300mAh battery pack

Payment & Shipping Terms:

Minimum Order Quantity: 50 PCS
Price: USD 3-5
Packaging Details: 1pcs for one bag with UN38.3
Delivery Time: 7-25 days after order confirm
Payment Terms: TT, L/C
Get Best Price Contact Now

Detail Information

Material: LifePO4 Voltage: 12V
Capacity: 2300times Circle Time: 2000 Time
Warranty: 1 Year Pvc: Blue
Pcb: With PCB For Normal Performance Po No: PIFP
High Light:

lithium iron phosphate battery pack

,

12 volt lithium battery

Product Description

26650 12V LiFePO4 Battery Pack High Power High Rate For Power Tool



Key Data for 26650 12V LiFePO4 Battery Pack High Power High Rate For Power Tool



Place of Origin:

Guangdong China (Mainland)

Brand Name:

TAC

Model Name:

12V  2300mAh  LiFePO4 battery pack

Other Name:

IFR 12V 2300mAh battery

Nominal Voltage

12.8V

Nominal Capacity:

2300mAh

Size:

Size:79mm(H)*28mm(W)*103mm(L)

Weight:

 380g+-10g



Packing & Delivery:



MOQ:

100pcs and support the samples 1-50 set

Delivery Detail:

Sample with stock 3 days after T/T

Mass order with stock 7 days after T/T

Mass order with stock 7 days after T/T



Packing with UN38.3 Certficaton to avoid short circle

26650 12V LiFePO4 Battery Pack High Power  High Rate For Power Tool 0

26650 12V LiFePO4 Battery Pack High Power  High Rate For Power Tool 1



Specification for 26650 12VLiFePO4 Battery Pack High Power High Rate For Power Tool



No.

Item

General Parameter



Remark

1

Rated Capacity



2.3Ah

Standard discharge(0.5C)after standard charge(0.5C)



2

Minimal Rated

Capacity

2.1Ah

3

Nominal Voltage

12.8V



4

Cycle Life



Higher than 60% of the Initial Capacity of the Cells

◆Charge: CC@0.5C to 14.6V, then CV till current to 0.05C

◆Rest: 30min.

◆Discharge: 0.5C to 10.0V

◆Temperature:20±5℃

◆Carry out 800cycles

5

Discharge cut-off voltage

none

No over-discharge protection,10.0V recommended

6

Charging cut-off voltage



none

No over-charge protection,14.6V recommended

7

Cell and assembly method



IFR26650P-2.3AH

4S1P

8

Packing material

PVC





Charge and Discharge Performance Standard



No.



Item



General Parameter Remark
9

Standard charge



0.5C constant current(CC) charge to 14.6V,then constant voltage (CC)14.6V charge till charge current decline to ≤0.05C

Charge time : Approx 3.5h



10

Standard discharge



Constant current 0.5C

Cut-off voltage 10.0V


11 Maximum Charge Current 2.3A
12

Maximum Discharge Current



23A The surface of the battery pack do not exceed 65℃
13

Operation Temperature Range



Charge: 0~45℃

60±25%R.H.



Discharge: -10~50℃
14

Storage Temperature Range



Less than 1 year : 0~25℃



60±25%R.H.

at the shipment state

Less than 3 months:-5~35℃



15

Weight



Approx: 380.0g±10.0g
16

Pack Dimension



High:79mm
Width: 28mm
Length: 103mm







Features:



1. High energy density than normal Lithium cell

2. High open circuit voltage 12v meet various application

3. Wide range of operating temperature -10~50℃

4. Stable operating voltage and current 10C high rate

5. Long operating time 2000 times base on 100% DOD

6. Low self-discharge rate (less than 2% per year at 20°C).



Main Applications :

1. Utility meter (water, electricity, gas meter,AMR)

2. Alarm or security equipment (smoke alarm system, detector)

3. GPS tracking

4. Teal time clock

5. Digital control machine

6. Military

7. Remote monitoring systems

8. Car electronics



Picture&Drawing:

26650 12V LiFePO4 Battery Pack High Power  High Rate For Power Tool 2



Similar Production Appearance

26650 12V LiFePO4 Battery Pack High Power  High Rate For Power Tool 3



More similar Lifepo4 Battery pack form 12v -72v



26650 12V LiFePO4 Battery Pack High Power  High Rate For Power Tool 4



Cautions in use

To ensure proper use of the battery please read the manual carefully before using it.

   . Handling

  •  Do not expose to, dispose of the battery in fire.
  • Do not put the battery in a charger or equipment with wrong terminals connected.
  • Avoid shorting the battery
  • Avoid excessive physical shock or vibration.
  • Do not disassemble or deform the battery.
  • Do not immerse in water.
  • Do not use the battery mixed with other different make, type, or model batteries.
  • Keep out of the reach of children.

     . Storage

  • Store the battery in a cool, dry and well-ventilated area.

     . Disposal

  • Regulations vary for different countries.
  • Dispose of in accordance with local regulations.



Battery operation instruction

Discharging current

The discharging current does not have to surpass this specification book stipulation the biggest discharging current, the over sized electric current electric discharge can cause the battery capacity play to reduce and to cause the battery heat.



Electric discharge temperature

The battery discharge must carry on in the ambient temperature scope which this specification book stipulated.



Storing the Batteries

The battery should store in the product specification book stipulation temperature range. If has surpasses above for six months the long time storage, the discharge capacity will decrease sharply.



Period of Warranty

Because batteries utilize a chemical reaction, battery performance will deteriorate over time even if stored for a long period of time without being used. In addition, if the various usage conditions such as discharge, ambient temperature, are not maintained within the specified ranges the life expectancy of the battery may be shortened or the device in which the battery is used may be damaged by electrolyte leakage. Please change the battery in time.
