Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool

Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool

  • Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool
  • Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool
Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool
Product Details:
Place of Origin: Shenzhen zhuhai
Brand Name: TAC BATTERY
Certification: MSDS REACH ROHS
Model Number: PIFC0223
Payment & Shipping Terms:
Minimum Order Quantity: 200PCS
Price: usd 2.0-30
Packaging Details: Follow UN38.3 Rule
Delivery Time: 7 days for single cell 15-20 days for battery pack
Payment Terms: TT/LC
Supply Ability: 1000000pcs per month
Contact Now
Detailed Product Description
Material: Lifepo4 Capacity: 2300mah
Voltage: 3.2v Warranty: 1 Year
High Power: 10c OEM\ ODM: Acceptable
Circle Life: 2000times Pvc Color: Blue
Pack: Acceptable
High Light:

lithium iron phosphate battery pack

,

lifepo4 rechargeable batteries



Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool

Specification for Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool

No. Items Specifications

Remark



1

Nominal Capacity



2400mAh

0.2C Standard discharge



2

Minimum Capacity



2350mAh
3

Nominal Voltage



3.2V

Mean Operation Voltage



4

Delivery voltage



3.2~3.3V

Within 10 days from Factory



5

Charge Voltage

3.65V±0.03V

By standard charge method



6

Standard charging method



0.2C constant current,3.65V constant voltage charge to 3.65V,continue charging till current decline to ≤0.01C



7

Charge current



1C 400mA

Standard charge, charge time about 6h(Ref)



1C 1000mA

Rapid Charge, charge time about: 3h(Ref)



8

Standard discharging method



10C constant current discharge to2.0V, 10C
9

Cell Internal Impedance



≤20mΩ

Internal resistance measured at AC 1KHZ after 50% charge





Performance of Charge and Discharge for IFR26650



No. Items Specifications/

Remark



10

Maximum charge current



10C

For continuous charging mod



11

Maximum discharge current



10C

For continuous discharge mod



12

Operation Temperature and relative humidity Range



Charge/

0~45℃

60±25%R.H.

Charge at a very low temperature such as blew 0℃,will be get a lower capacity and reduce cycle life of the battery



Discharge/

-20~60℃

60±25%R.H.

13

Storage temperature for a long time



-20~25℃

60±25%R.H.

Do not storage exceed half year. Must charge once when storage for half year. must charge the battery which with protect circuit when storage for three months.





Features:

This cell is deep circle lifepo4 battery , the model is IFR26650  2300MAH 3.2V, the Max Max discharge current can reach 10C.The single cell can do the battery pack or solder the tabs and assemble to any pack with your require, the battery performance including Excellent abuse tolerance and environmentally friendly ,

Excellent calendar life, 10X cycle life vs. conventional lithium ion, With greater  high power and energy density and lower impedance. the battery is normal and major production for us , so we can  Offers an excellent combination of price-performance.



Application For Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool



  1. Portable high power devices Power tool
  2. Solar Product, GPS
  3. Stationary battery backup systems
  4. Grid stabilization energy storage systems
  5. Commercial truck and bus hybrid electric vehicles (HEVs)

Drawing for  Cell

Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool 0

Packing for cell similar as below

10pcs in one inner box

8 box in one standard export carton

Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool 1

Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool 2



Other Cylindrical LiFePO4 Battery High power Energy Type:

Model

Nominal

Internal

Capacity

Cell Size(mm)

Weight

Voltage

Resistance

(mAh)

(g)

(V)

(Max mΩ)



Diameter

Height



LFR14430

3.2

110

250

13.9

43.0

12

LFR14500

3.2

100

650

13.9

50.2

18

LFR15270

3.2

140

200

15.0

27.0

10

LFR18500

3.2

60

1000

18

50

32

LFR18500

3.2

80

1200

18

50

32

LFR18650

3.2

65

1400

18

64.8

39

LFR18650

3.2

65

1500

18

64.8

40

LFR18650

3.2

80

1700

18

64.8

41

LFR26650

3.2

20

3000

26

65.3

84

LFR26650

3.2

20

3300

26

65.3

86



Pictures:



Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool 3

Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool 4





Lifepo4 Battery Pack with Lifepo4 26650

Rechargeable Lithium Batteries IFR26650 3.2V 2300mAh 10C for Power Tool 5
