Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A

Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A

    • Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A
    • Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A
  • Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A

    Product Details:

    Place of Origin: guangzhou
    Brand Name: TAC
    Certification: UL, ROHS
    Model Number: PIF0002

    Payment & Shipping Terms:

    Minimum Order Quantity: 200pcs
    Price: usd 0.82 each pcs
    Packaging Details: 50PCS/BOX , 8 box / carton
    Delivery Time: 7-14days for bulk
    Payment Terms: TT, LC, Paypal etc
    Supply Ability: 100,000pcs/Day
    Contact Now
    Detailed Product Description
    Material: Lifepo4 Rechargeable: Yes
    Circle Life: 2000times Size: 16.5*34.5mm
    Other Name: RCR123A Warranty: 12month
    Capacity: 450mah Voltage: 3.2v
    Pvc: Blue Or Green

    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A


    Features For Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A



    1. Model name:IFR17335  450mAh 1.35Wh  or IFR16340 450MAH 1.35WH

    2. International normal name: Rechargeable RCR123A

    3. long circle life: 2000times

    4. The battery is rechargeable battery , and the voltage is 3.2v same as the primary CR123A and can instead of it .



    Application FOR Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A




    1. flash light and digital camare

    2. Portable high power devices

    3. Stationary battery backup systems

    4. Grid stabilization energy storage systems

    5. Commercial truck and bus hybrid electric vehicles (HEVs)




    Battery Specification List


    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A

    No.

    Items

    Specifications

    Remark

    1

    Nominal Capacity

    450mAh

    0.2C Standard discharge

    2

    Minimum Capacity

    400mAh

    3

    Nominal Voltage

    3.2V

    Mean Operation Voltage

    4

    Delivery voltage

    3.28~3.32V

    Within 10 days from Factory

    5

    Charge Voltage

    3.65V±0.03V

    By standard charge method

    6

    Standard charging method

    0.2C constant current,3.65V constant voltage charge to 3.65V,continue charging till current decline to ≤0.01C



    7

    Charge current

    0.2C

    120mA

    Standard charge, charge time about 7h(Ref)

    1.0C

    600mA

    Rapid Charge, charge time about: ::1.5h(Ref)

    8

    Standard discharging method

    0.2C constant current discharge to 2.5V,



    9

    Cell Internal Impedance

    ≤60mΩ

    Internal resistance measured at AC 1KHZ after 50% charge



    Charge And Discharge Performance



    10

    Maximum charge current

    1C

    450mA

    For continuous charging mod

    11

    Maximum discharge current

    2C

    900mA

    For continuous discharge mod(Discharge capacity for more than 80% of the nominal capacity)


    12

    Operation Temperature and relative humidity Range

    Charge

    0~45℃
    60±25%R.H.

    Charge at a very low temperature such as blew 0℃,will be get a lower capacity and reduce cycle life of the battery

    Discharge

    -20~60℃
    60±25%R.H.

    13

    Storage temperature for a long time

    -20~25℃
    60±25%R.H.

    Do not storage exceed half year. Must charge once when storage for half year. must charge the battery which with protect circuit when storage for three months.




    Packing Photo

    50pcs / inner box ,  8 box / carton

    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A
    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A


    Pictures For Rechargeable 123A Batteries Lifepo4 3.0V Instead Of Panasonic CR123A






    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A











































































    The Similar Model For Lithium-ion Cylindrical Battery



    MODEL CAPACITY VOLTAGE
    IFR10120 35 3.2V
    IFR10440 200 3.2V
    IFR14430 300 3.2V
    IFR14430 400 3.2V
    IFR14430 450 3.2V
    IFR14430 FLAT 450 3.2V
    IFR14430 500 3.2V
    IFR14505 250 3.2V
    IFR14505 300 3.2V
    IFR14505 400 3.2V
    IFR14500 FLAT 600 3.2V
    IFR14505 600 3.2V
    IFR15270 200 3.2V
    IFR17335 450 3.2V
    IFR18500 600 3.2V
    IFR18500 800 3.2V
    IFR18500 1000 3.2V
    IFR18650 1000 3.2V
    IFR18650P 1100 3.2V
    IFR18650 1200 3.2V
    IFR18650 1500 3.2V
    IFR26650 3000 3.2V
    IFR26650 3300 3.2V

    The Certfication for Lifepo4 Battery

    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A



    Production Line for Lifepo4 Battery

    Rechargeable 123A Batteries Lifepo4 3.0V Instead Of  Panasonic CR123A
