Customized LiFeO4 Battery Pack 3.2V 6.4V 9.6V 12.8V 16V 32v 36v 48v 60v 72v 96v
Product Details:
| Place of Origin: | GUANGZHOU |
| Brand Name: | Sunland or ODM |
| Certification: | UL1642 MSDS REACH |
| Model Number: | IFR32700 1S2P |
Payment & Shipping Terms:
| Minimum Order Quantity: | 200PCS |
|---|---|
| Price: | USD22.3 |
| Packaging Details: | 100PCS per carton |
| Delivery Time: | 15-25 days after order confirm |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50000 per week |
|
Detail Information |
|||
| Type: | LiFepo4 Battery Pack | Cell Model: | IFR32700 |
|---|---|---|---|
| Structure: | 2S2P | Size: | 39x138x77mm |
| Function: | Solar Energy | Working Current: | 20A |
| Cable Lenth: | 200mm | Parameter: | 6.4V 12AH |
| Highlight: | 3.2V LiFeO4 Battery Pack,96v LiFeO4 Battery Pack |
||
Product Description
Customized LiFeO4 battery pack 3.2V 6.4V 9.6V 12.8V 16V 32v 36v 48v 60v 72v 96v
4. This GuangZhou Sunland New Energy Tech.Co.,Ltd LiFePO4 battery is a great option for those who need a reliable and powerful power source. It has amazing high temperature performance, making it perfect for use in electronic fence applications.
|
No. |
Items |
Specifications |
Remark |
|
1 |
Capacity for assembled cell discharging by 0.2C |
≥11.6Ah |
Standard discharging method |
|
2 |
Battery Voltage |
≥6.4V |
Base on MOQ 10K Within 10 days from Factory |
|
Battery SOC |
Appr 30% | ||
|
3 |
Standard charge condition |
Charge with 20A constant current and 7.3V constant voltage, charge to 7.3V,continue charging till current decline to ≤0.01C |
Charge voltage: 7.3V±0.03V Charge current:20A |
| 4 |
Max continuous charge current |
20A |
|
|
5 |
Standard discharging method |
20A constant current discharge to 4 V, |
|
| 6 |
Max continuous discharge current |
20A |
|
|
7 |
Internal Impedance |
Assemblage Impedance |
Measure the Red and black wire of the connector after assembling. |
| 8 |
Charge upper limit temperature |
0-45℃ |
Charging at low temperature, capacity and cycle life will reduce. |
| 9 |
Discharge upper limit temperature |
-20-60℃ | |
| 10 | Connector | None |
|
| 11 | Wire | UL1007 16AWG |
Outside diameter Max :1.5mm |
| 12 | Date code | Cell date code and battery date code not beyond 3month | |
| 13 | Vbatt(OCV) | 7.3±0.05V |
Customized LiFeO4 battery pack 3.2V 6.4V 9.6V 12.8V 16V 32v 36v 48v 60v 72v 96v
|
|
|
No |
Working temperature |
Charging Spec |
Discharging Spec |
|
1 |
-20oC to 0oC |
Charge current limited to 0.1C(1.2A) or |
Suggest discharge current limited to 0.2C or |
| 2 | 0oC to 45oC | Charge current within spec | Discharge current within spec |
|
3 |
45oC to 70oC |
Charge current limited to 0.1C(1.2A) or below Cut off voltage 3.60Vor below |
Suggest discharge current limited to 0.2C or below |
|
|
