IFR32700 4S3P 12.8V 18Ah For Solar flood light High Bright LEDS Garden Solar Lights lifepo4 battery
Product Details:
| Place of Origin: | GUANGZHOU CHINA |
| Brand Name: | Sunland |
| Certification: | CE,SGS recognized,ISO9001 approved |
| Model Number: | IFM12-180E2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | USD39-41/PCS |
| Delivery Time: | 10-30 DAYS |
| Supply Ability: | 10000 PCS PER WEEK |
|
Detail Information |
|||
| Features: | Long Cycle Life | Nominal Capacity: | 18Ah |
|---|---|---|---|
| Circle Time: | 2000 Times | Cell Type: | Lifepo4 Cell |
| Discharger Current: | 10C | Chemistry: | Lithium Iron Phosphate (LiFePO4) |
| Pack: | Assembled With Customer Require | Cell Size: | T: 2.7 * W:135 *H206MM |
| Cycle Span: | 2000 Cycles | Maximum Charge Current: | 1C |
| The Discharge Rate: | 1C | The Charging Ratio: | 0.2C-1C |
| Application: | Electric Fencing | Energy: | 4.8Wh |
| Terminal: | M8 | ||
| Highlight: | High Bright LEDS lifepo4 battery,4S3P lifepo4 battery,12.8V 18Ah lifepo4 battery |
||
Product Description
IFR32700 4S3P 12.8V 18AH
Battery specifications/产品规格12V 18AH
| NO |
Items/项目 |
Specifications/规格 |
Remark备注 | |
| 1 |
Normal Capacity 额定容量 |
18Ah |
Standard discharging method 标准放电方式 |
|
| 2 |
Nominal voltage 额定电池电压 |
12.8V |
|
|
| 3 |
Standard charge condition 标准充电条件 |
CC 0.2C (3.6A)@ 14.6V, till current decline to ≤0.05C
|
CC 0.2C(3.6A) 恒流充至14.6V, 恒压充至电流≤0.05C
|
|
| 4 |
Max charge current 最大持续充电电流 |
20A |
||
| 5 |
Standard discharging method 标准放电方式 |
CC 0.2C(3.6A) @ 10V | ||
| 6 |
Max discharge current 最大持续放电电流 |
20A | ||
| 7 |
Weight 重量 |
2.3KG | ||
| 8 |
Dimension 尺寸 |
150mm*100mm*100mm(±2mm) | ||
| 9 |
Plastic case 塑胶壳 |
ABS | ||
| 10 |
Operation Temperature and relative humidity Range 工作温度和湿度范围 |
Charge/充电 |
0~45℃ 60±25%R.H. |
|
| Discharge/ 放电 |
-20~60℃ 60±25%R.H. |
|||
| 11 |
Storage temperature for a long time 长时间储存温度 |
-20~25℃ | Each half year, charge and discharge one time 长时储存至少每半年充放电一次 | |
Want to Know more details about this product
